NON AI-PT-DASHCAM
NON AI-PT Dashcam, a 4G LTE real-time networked dashcam with GNSS satellite positioning and real-time video recording capabilities. Here's a summary of the key specifications and features:
Physical & Hardware:
· Dimensions: 105mm x 86mm x 32mm, Weight: 240g
· Module: RC10E, LTE Cat1/GNSS
· Linux system, HC1723C chip
· 2.0MP sensor, 1920x1080 resolution
· Forward lens: 3.6mm, 110° view angle; Backward lens: 2.8mm, 140° view angle
· Internal high-gain GNSS and 4G antennas
· 3 status LED lights (blue, green, red), Micro-SIM slot
· Supports TF card up to 128GB
· Built-in speaker and mic
GNSS:
· Supports GPS, GLONASS, GALILEO, BEIDOU, AGPS, QZSS, SBAS
· 64-channel receiver, tracking sensitivity -160dB
· Position accuracy <2.0m CEP, velocity accuracy <0.1m/s
· Hot start <1s, warm start <4s, cold start <28s
Cellular:
· LTE Cat1, bands: FDD B1/B3/B5/B8/B34; TDD B38/B39/B40/B41
· Data transfer: Max 10Mbps DL / 5Mbps UL
· SMS support (TXT/PDU)
Power:
· Input voltage: 9~36V DC
· Power consumption at 12V: <6mA (online sleep), <150mA (normal), <270mA (full load)
Operating Environment:
· Operating temp: -20°C to +70°C; Storage: -40°C to +85°C
· Humidity: 5% to 95% non-condensing
Interfaces:
· 2 digital inputs
· Power cable: Red (Power+), Black (Power GND), Orange (ACC)
Key Functions:
· Auto video recording on power-up, 1080P HD loop recording
· 4G communication for uploading data, video, driving track, and alarms
· Real-time GPS & BD dual-mode positioning
· Vibration alarm (when ACC off, detects vibration, triggers alarm, uploads photo, wakes device for 5-min recording)
· Collision alarm (during driving, triggers immediately and uploads video from first 10s to 5s before collision)
Installation:
· Can be powered via replacement fuse or USB power cable from cigarette lighter
· If using USB power, recorder only works when vehicle is started; turns off when vehicle is switched off
Product Display:
· Sliding closure, backward-facing and forward-facing cameras, SIM cover, speaker, MIC
· LED indicators: blue, green, red
